SMS W2- 1 Ton Hydraulic Winch Gearbox

Specifically designed for water well and diverse drilling machines, this SMS Winch solution boasts a robust 1-ton lifting capacity. Whether you are managing deep-bore operations or site-specific drilling, our gearbox provides the mechanical advantage necessary for smooth, controlled vertical movement. Rated for 1,000kg (1 Ton), ensuring safety and efficiency for medium-scale drilling applications. Equipped with a precision-machined sprocket attachment for seamless chain drives, allowing for versatile installation across various machine types. Designed to integrate perfectly with standard hydraulic systems, minimizing energy loss and heat generation. Built with high-grade materials to withstand the abrasive environments of drilling sites.

• Product Details
• Technical Specification

Application	WaterWell Rig Blast Hole Rig Solar Pile Rig
Lifting Method	Sprocket/ Drum
Lifting Capacity	1 Ton
Driving Method	Hydraulic Motor Operated (OMP Series Motor)
Mounting	Truck/ Crawler/ Tractor

Ratio	18:1 (Customisable)
Max Torque	2000 Nm
Max Lifitng Speed	20 m/s
Housing	Single Piece Steel Casting
Self Locking	Clutch/ Worm
Gearbox Weight	30 Kg's without motor
